1. Since the product is completely manufactured with flame retardant material, it features low loss, low temperature rise, high safety level and complete protection function. 2. It is mainly used for the isolation power supply of various medical devices.
Product description:
1. Since the product is completely manufactured with flame retardant material, it features low loss, low temperature rise, high safety level and complete protection function.
2. It is mainly used for the isolation power supply of various medical devices.
Technical parameters:
|
Technical Parameters of Isolation Transformer for Medical Device |
|||
|
Item |
Standard Value |
Condition |
|
|
1 |
Capacity |
1KVA-500KVA |
|
|
2 |
Voltage range |
＜1000V |
|
|
3 |
Insulation resistance |
＞100M? |
DC1000V |
|
4 |
Dielectric strength |
＜20mA |
AC3.0KV 60s |
|
5 |
Efficiency |
≥97% |
Full load |
|
6 |
Noise |
≤65dB |
1m away from transformer |
|
7 |
Temperature rise |
≤90K |
Full load, self cooling |
|
8 |
Insulation class |
Class H (180℃) |
|
|
9 |
Connection mode |
Dyn11 |
|
|
10 |
Short-circuit impedance |
3% |
|
|
11 |
Ambient temperature |
0℃ - 35℃ |
|
|
12 |
Design standard |
GBT10228 |
|
|
|
Medical device |
